East Coast Supercharging Lysholm 2010+ Camaro Supercharger Kit User Manual

Page 18

P/N: 4LGE020-010 v1.1, 2011-04-29

N. Disconnect the driver-side main coil bracket

harness by releasing the green clip lock and

separating the connector by lifting the con-

nector tab. See fig 1S, 1T.

O. Disconnect the four (4) driver-side spark plug

wires from the bottom of each ignition coil.

See fig 1U.

Fig 1S

Fig 1T

Fig 1U
