East Coast Supercharging Lysholm 2010+ Camaro Supercharger Kit User Manual

Page 16

P/N: 4LGE020-010 v1.1, 2011-04-29

K. Once the coolant is drained, remove the fac-

tory clamps securing the heater hoses at the

water pump and the firewall.

L. Set hoses aside as they will not be reused.

Fig 1N

Fig 1O

Fig 1P

NOTE: It may be easier to remove the clamps at the fire-

wall after intake manifold removal.
