DES-3010F/DES-3010FL/DES-3010G/DES-3016/DES-3018/DES-3026 Fast Ethernet Switch Manual
81
Figure 6- 64. DHCP/BOOTP Relay Interface Settings and DHCP/BOOTP Relay Interface Table window
The following parameters may be configured or viewed.
Parameter Description
Interface The IP interface on the Switch that will be connected directly to the Server.
Server IP Enter the IP address of the DHCP/BOOTP server. Up to four server IPs can be configured
per IP Interface
DHCP Relay Option 60 Default Settings
This function allows the user to set up the DHCP Relay Option 60 Default Settings. When there are no
servers found that are suitable for the packet based on option 60, the relay servers will be determined by the
default relay server setting. To view this window, click Administration > DHCP/BOOTP Relay > DHCP
Relay Option 60 Default Settings
Figure 6- 65. DHCP Relay Option 60 Default Settings window
The following parameters may be configured or viewed.
Parameter Description
Relay IP Address Enter the ip address that the
Mode Drop – When drop is specified, the packet with no matching rules found will be dropped
without further process.
Relay – When relay is specified the packet will be processed further based on option 61.
The final relay servers will unite option 60 default relay servers and the relay servers
determined by option 61.
