DES-3010F/DES-3010FL/DES-3010G/DES-3016/DES-3018/DES-3026 Fast Ethernet Switch Manual
181
MAC Address
Figure 11- 16. MAC Address Table
The following fields can be viewed or set:
Parameter Description
VLAN Name Enter a VLAN Name by which to browse the forwarding table.
MAC Address Enter a MAC address by which to browse the forwarding table.
Port Select the port by using the corresponding pull-down menu.
Find Allows the user to move to a sector of the database corresponding to a user defined port,
VLAN, or MAC address.
VID The VLAN ID of the VLAN of which the port is a member.
MAC Address The MAC address entered into the address table.
Port The port to which the MAC address above corresponds.
Type Describes the method which the Switch discovered the MAC address. The possible entries
are Dynamic, Self, and Static.
Next Click this button to view the next page of the address table.
View All Entry Clicking this button will allow the user to view all entries of the address table.
This allows the Switch's dynamic
MAC address forwarding table to be
viewed. When the Switch learns an
association between a MAC address
and a port number, it makes an entry
into its forwarding table. These
entries are then used to forward
packets through the Switch.
To view the MAC Address
forwarding table, click Monitoring >
MAC Address
