DES-3010F/DES-3010FL/DES-3010G/DES-3016/DES-3018/DES-3026 Fast Ethernet Switch Manual
153
Initializing Ports for Port Based 802.1X
Existing 802.1X port and MAC settings are displayed and can be configured using the window below.
To view the following window, click Security > 802.1X > Initialize Port(s)
Figure 10- 18. Initialize Port window
This window allows you to initialize a port or group of ports. The Initialize Port Table in the bottom half of
the window displays the current status of the port(s).
This window displays the following information:
Parameter Description
From and To Select ports to be initialized.
Port A read only field indicating a port on the Switch.
MAC Address The MAC address of the Switch connected to the corresponding port, if any.
Auth PAE State The Authenticator PAE State will display one of the following: Initialize, Disconnected,
Connecting, Authenticating, Authenticated, Aborting, Held, ForceAuth
or ForceUnauth.
Backend_State The Backend Authentication State will display one of the following: Request, Response,
Success, Fail, Timeout, Idle
or Initialize.
Open Dir The Operational Controlled Directions are both and in.
PortStatus The status of the controlled port can be Authorized or Unauthorized.
