DES-3010F/DES-3010FL/DES-3010G/DES-3016/DES-3018/DES-3026 Fast Ethernet Switch Manual

190

Parameter Description

Port

The identification number assigned to the Port by the System in which the Port resides.

EntersConnecting

Counts the number of times that the state machine transitions to the CONNECTING
state from any other state.

EapLogOffsConnecting

Counts the number of times that the state machine transitions from CONNECTING to
DISCONNECTED as a result of receiving an EAPOL-Logoff message.

EntersAuthenticating

Counts the number of times that the state machine transitions from CONNECTING to
AUTHENTICATING, as a result of an EAP-Response/Identity message being received
from the Supplicant.

SuccessAuthenticating

Counts the number of times that the state machine transitions from
AUTHENTICATING to AUTHENTICATED, as a result of the Backend Authentication
state machine indicating successful authentication of the Supplicant (authSuccess =
TRUE).

TimeoutsAuthenticating

Counts the number of times that the state machine transitions from
AUTHENTICATING to ABORTING, as a result of the Backend Authentication state
machine indicating authentication timeout (authTimeout = TRUE).

FailAuthenticating

Counts the number of times that the state machine transitions from
AUTHENTICATING to HELD, as a result of the Backend Authentication state machine
indicating authentication failure (authFail = TRUE).

ReauthsAuthenticating

Counts the number of times that the state machine transitions from
AUTHENTICATING to ABORTING, as a result of a reauthentication request
(reAuthenticate = TRUE).

EapStartsAuthenticating

Counts the number of times that the state machine transitions from
AUTHENTICATING to ABORTING, as a result of an EAPOL-Start message being
received from the Supplicant.

EapLogOffAuthenticating

Counts the number of times that the state machine transitions from
AUTHENTICATING to ABORTING, as a result of an EAPOL-Logoff message being
received from the Supplicant.

ReauthsAuthenticated

Counts the number of times that the state machine transitions from AUTHENTICATED
to CONNECTING, as a result of a reauthentication request (reAuthenticate = TRUE).

EapStartsAuthenticated

Counts the number of times that the state machine transitions from AUTHENTICATED
to CONNECTING, as a result of an EAPOL-Start message being received from the
Supplicant.

EapLogOffAuthenticated

Counts the number of times that the state machine transitions from AUTHENTICATED
to DISCONNECTED, as a result of an EAPOL-Logoff message being received from
the Supplicant.

Responses

Counts the number of times that the state machine sends an initial Access-Request
packet to the Authentication server (i.e., executes sendRespToServer on entry to the
RESPONSE state). Indicates that the Authenticator attempted communication with the
Authentication Server.

AccessChallenges

Counts the number of times that the state machine receives an initial Access-
Challenge packet from the Authentication server (i.e., aReq becomes TRUE, causing
exit from the RESPONSE state). Indicates that the Authentication Server has
communication with the Authenticator.

OtherReqToSupp

Counts the number of times that the state machine sends an EAP-Request packet
(other than an Identity, Notification, Failure, or Success message) to the Supplicant
