DES-3010F/DES-3010FL/DES-3010G/DES-3016/DES-3018/DES-3026 Fast Ethernet Switch Manual
72
Forwarding & Filtering
Unicast Forwarding
To view or configure the Unicast Forwarding window click, Administration > Forwarding & Filtering >
Unicast Forwarding
Figure 6- 56. Setup Static Unicast Forwarding Table and Static Unicast Forwarding Table window
To add or edit an entry, define the following parameters and then click Add/Modify:
Parameter Description
VLAN ID (VID) The VLAN ID number of the VLAN on which the above Unicast MAC address resides.
MAC Address The MAC address to which packets will be statically forwarded. This must be a unicast
MAC address.
Port Allows the selection of the port number on which the MAC address entered above
resides.
Click Apply to implement the changes made. Current entries can be found in the Static Unicast
Forwarding Table as shown in the bottom half of the figure above. To delete an entry in the Static Unicast
Forwarding Table, click the corresponding under the Delete heading.
