DES-3010F/DES-3010FL/DES-3010G/DES-3016/DES-3018/DES-3026 Fast Ethernet Switch Manual
139
Port Lock Entries
The Port Lock Entry Delete window is used to remove an entry from the port security entries learned by
the Switch and entered into the forwarding database. To view the following window, click Security > Port
Lock Entries
Figure 10- 3. Port Lock Entries Table
This function is only operable if the Mode in the Port Security window is selected as Permanent or
DeleteOnReset, or in other words, only addresses that are permanently learned by the Switch can be
deleted. Once the entry has been defined by entering the correct information into the window above, click
the under the Delete heading of the corresponding MAC address to be deleted. Click the Next button to
view the next page of entries listed in this table. This window displays the following information:
Parameter Description
VID The VLAN ID of the entry in the forwarding database table that has been permanently learned by
the Switch.
VLAN NAME The VLAN Name of the entry in the forwarding database table that has been permanently learned
by the Switch.
MAC Address The MAC address of the entry in the forwarding database table that has been permanently learned
by the Switch.
Port The ID number of the port that has permanently learned the MAC address.
Type The type of MAC address in the forwarding database table. Only entries marked
Secured_Permanent
can be deleted.
Delete Click the in this field to delete the corresponding MAC address that was permanently learned by
the Switch.
