DES-3010F/DES-3010FL/DES-3010G/DES-3016/DES-3018/DES-3026 Fast Ethernet Switch Manual

51

To add a new entry to the Switch's SNMP Group Table, click the Add button in the upper left-hand corner
of the SNMP Group Table page. This will open the SNMP Group Table Configuration page, as shown
below.

Figure 6- 28. SNMP Group Table Configuration – Add window

The following parameters can set:

Parameter Description

Group Name

Type an alphanumeric string of up to 32 characters. This is used to identify the new SNMP
group of SNMP users.

Read View Name

This name is used to specify the SNMP group created can request SNMP messages.

Write View Name

Specify a SNMP group name for users that are allowed SNMP write privileges to the
Switch's SNMP agent.

Notify View Name

Specify a SNMP group name for users that can receive SNMP trap messages generated
by the Switch's SNMP agent.

Security Model

SNMPv1

- Specifies that SNMP version 1 will be used.

SNMPv2

- Specifies that SNMP version 2c will be used. The SNMPv2 supports both

centralized and distributed network management strategies. It includes improvements in
the Structure of Management Information (SMI) and adds some security features.

SNMPv3

- Specifies that the SNMP version 3 will be used. SNMPv3 provides secure

access to devices through a combination of authentication and encrypting packets over the
network.

Security Level

The Security Level settings only apply to SNMPv3.

NoAuthNoPriv

- Specifies that there will be no authorization and no encryption of

packets sent between the Switch and a remote SNMP manager.

AuthNoPriv

- Specifies that authorization will be required, but there will be no

encryption of packets sent between the Switch and a remote SNMP manager.

AuthPriv

- Specifies that authorization will be required, and that packets sent

between the Switch and a remote SNMP manger will be encrypted.

To implement your new settings, click Apply. To return to the SNMP Group Table, click the

Show All

SNMP Group Table Entries

link.
