DES-3010F/DES-3010FL/DES-3010G/DES-3016/DES-3018/DES-3026 Fast Ethernet Switch Manual
171
Figure 11- 6. Rx Packets Analysis window (table for Unicast, Multicast, and Broadcast Packets)
The following fields may be set or viewed:
Parameter Description
Time Interval [1s] Select the desired setting between 1s and 60s, where "s" stands for seconds. The default
value is one second.
Record Number [200] Select number of times the Switch will be polled between 20 and 200. The default value is
200.
Unicast Counts the total number of good packets that were received by a unicast address.
Multicast Counts the total number of good packets that were received by a multicast address.
Broadcast Counts the total number of good packets that were received by a broadcast address.
Show/Hide Check whether or not to display Multicast, Broadcast, and Unicast Packets.
Clear Clicking this button clears all statistics counters on this window.
View Table Clicking this button instructs the Switch to display a table rather than a line graph.
View Line Chart Clicking this button instructs the Switch to display a line graph rather than a table.
