DES-3010F/DES-3010FL/DES-3010G/DES-3016/DES-3018/DES-3026 Fast Ethernet Switch Manual
173
Figure 11- 8. Tx Packets Analysis window (table for Bytes and Packets)
The following fields may be set or viewed:
Parameter Description
Time Interval [1s] Select the desired setting between 1s and 60s, where "s" stands for seconds. The default
value is one second.
Record Number [200] Select number of times the Switch will be polled between 20 and 200. The default value is
200.
Bytes Counts the number of bytes successfully sent from the port.
Packets Counts the number of packets successfully sent on the port.
Unicast Counts the total number of good packets that were transmitted by a unicast address.
Multicast Counts the total number of good packets that were transmitted by a multicast address.
Broadcast Counts the total number of good packets that were transmitted by a broadcast address.
Show/Hide Check whether or not to display Bytes and Packets.
Clear Clicking this button clears all statistics counters on this window.
View Table Clicking this button instructs the Switch to display a table rather than a line graph.
View Line Chart Clicking this button instructs the Switch to display a line graph rather than a table.
