DES-3010F/DES-3010FL/DES-3010G/DES-3016/DES-3018/DES-3026 Fast Ethernet Switch Manual
150
802.1X Capability Settings
Figure 10- 15. 802.1X Capability Settings and Table window
To set up the Switch's 802.1X port-based authentication, select which ports are to be configured in the From
and To fields. Next, enable the ports by selecting Authenticator from the drop-down menu under
Capability. Click Apply to let your change take effect.
Configure the following 802.1X capability settings:
Parameter Description
From and To Ports being configured for 802.1X settings.
Capability Two role choices can be selected:
Authenticator - A user must pass the authentication process to gain access to the network.
None - The port will not be controlled by the 802.1X function.
Click Security > 802.1X > 802.1X Capability
Settings to view the following window:
