DES-3010F/DES-3010FL/DES-3010G/DES-3016/DES-3018/DES-3026 Fast Ethernet Switch Manual
166
To view the CPU utilization by port, use the real-time graphic of the Switch at the top of the web page by
simply clicking on a port. Click Apply to implement the configured settings. Click Clear to automatically
refresh with new updated statistics.
The information is described as follows:
Parameter Description
Time Interval [1s ] Select the desired setting between 1s and 60s, where "s" stands for seconds. The default
value is one second.
Record Number [200] Select number of times the Switch will be polled between 20 and 200. The default value is
200.
Show / Hide Check whether or not to display CPU utilization for five seconds, one minute or five minutes.
Port Utilization
The Port Utilization page displays the percentage of the total available bandwidth being used on the port.
To view the port utilization, click Monitoring > Port Utilization
Figure 11- 2. Port Utilization window
The user may use the real-time graphic of the Switch at the top of the web page to view utilization statistics
per port by clicking on a port. The following field can be set:
