D-Link DES-3018 - Manual (Page 66)

DES-3010F/DES-3010FL/DES-3010G/DES-3016/DES-3018/DES-3026 Fast Ethernet Switch Manual
53
SNMP Host Table
Use the SNMP Host Table to set up SNMP trap recipients.
To view the SNMP Host Table window click Administration > SNMP Manager > SNMP Host Table
Figure 6- 30. SNMP Host Table
To delete an existing SNMP Host Table entry, click the corresponding button under the Delete heading.
To add a new entry to the Switch's SNMP Host Table, click the Add button in the upper left-hand corner of
the page. This will open the SNMP Host Table Configuration page, as shown below.
Figure 6- 30. SNMP Host Table Configuration window
The following parameters can set:
Parameter Description
Host IP Address Type the IP address of the remote management station that will serve as the SNMP host
for the Switch.
SNMP Version V1 - To specifies that SNMP version 1 will be used.
V2 - To specify that SNMP version 2 will be used.
V3-NoAuth-NoPriv - To specify that the SNMP version 3 will be used, with a NoAuth-
NoPriv security level.
V3-Auth-NoPriv - To specify that the SNMP version 3 will be used, with an Auth-NoPriv
security level.
V3-Auth-Priv - To specify that the SNMP version 3 will be used, with an Auth-Priv security
level.
Community String or
SNMP V3 User Name Type in the community string or SNMP V3 user name as appropriate.
To implement your new settings, click Apply. To return to the SNMP Host Table, click the Show All
SNMP Host Table Entries link.
