Form I-Y, P/N 273646R6, Page 9

Bottom View showing Duct Openings

X

Y

55-5/64

(1399)

62-1/64

(1575)

**Optional

Disconnect

Switch

**Power

Supply

12-5/64

(307)

Gas

Inlet

Utility Entrance Dimensions

57

(1448)

57

(1448)

31

(787)

32-43/64

(830)

21

(533)

6-9/64

(156)

6-9/64

(156)

32-57/64

(835)

Condenser

Section

Outside Air

Inlet

Power Exhaust

Box with

Optional Wheel

59-5/8

(1514)

5-27/32

(148)

7-29/64

(189)

Z

78-61/64

(2005)

12-1/2

(317)

Return Air

Inlet

Supply Air Discharge

Fan

Access

Optional

Wheel

Access

Damper

Access

Hood

Coil Access

Filter Access

Power

Exhaust

Box with

Optional

Wheel

23-15/16

(608)

1” PVC Female

Condensate Drain Pan

Adapter Fitting

(Inside the Curb Cap)

(Base Length)

Side View (with power exhaust)

Optional

Outside Air

Hood

Top View

Vent Outlet - Standard (non-condensing)

Gas Heat Section

101-5/32

(2569)

Inlet Air End View

Control Access

Optional Heat

Section

Condenser

Section

5

(127)

Vent Outlet

(gas heat)

64-23/32 (1644)

(Inside Curb Cap)

Control End View with Electric or

Non-Condensing Gas Heat Section

83-3/64

(2109)

70-11/16

(1795)

49-25/64

(1255)

Control End View with High

Efficiency Gas Heat Section

(See dimensions below)

Optional Gas

Heat Section

Control Access

*Vent Outlets High

Efficiency (condensing)

Gas Heat Section

* High efficiency dual heat sections have two vent outlets.

** Two power supply entrances and two disconnect switches apply only

to systems with dual disconnect Option BA7

161-11/32

(4098)

155-23/32

(3955)

164-9/32

(4173)

83-31/32

(2133)

FIGURE 4 - Cabinet Size 3 Dimensions - inches (mm)

Important NOTE: DO NOT use base dimensions for roof curb. See Paragraph 5.3.

Gas Connection Location and Size for Systems with Optional Gas Heat Section

Gas Heat Section (H=non-condensing; G=condensing heat section)

X

Y

Diameter

(NPT)

Single Furnace

Dual Furnaces (one gas connection)

G150, H200

G302, H402

9-35/64”

(242 mm)

19-5/32”

(487 mm)

1/2”

--

H150, H175, H202

12-21/32”

19-5/32”

(487 mm)

1/2”

G225, G300, H300, H400

G372, G452, H502, H602

9-13/32”

(239 mm)

19-37/64”

(497 mm)

3/4”

--

G525, G602, H702, H802

1-1/4”

Opening Dimensions

inches (mm)

Supply Air

Discharge

57 x 31

(1448) x (787)

Return Air Inlet

57 x 21

(1448) x (533)

Outside Air Inlet - Sizes by Option:
Option

Z

AR1, AR25,

AR2G & all

other models

30-5/8

(778)

AR7

8-1/16

(205)

ER

V

Wheel Access

Side View

(with ERV Wheel Option)

Damper

Access

Optional

Exhaust

Damper

Side View

(with Optional Exhaust Damper)
