3 field wiring by control option (cont’d), Option cl23 option cl33, Discharge air temperature sensor (cont’d) – Reznor YDSA Unit Installation Manual User Manual
Page 29

Form I-Y, P/N 273646R6, Page 29
ID1
ID2
IDC1
ID3
ID4
ID5
ID6
ID7
15
ID8
CONTACTS
CALL FOR DEHUMIDIFICATION
J5
15
PR
PR
FACTORY INSTALLED OCCUPIED
JUMPER -- REMOVE JUMPER AND
REPLACE WITH EXTERNAL
CUSTOMER OCCUPIED CONTROL
OPTION CL23 or CL33
THERMOSTAT
15
16
(ADD R-RC
JUMPER)
W1
BL
W
Y
Y1
W1
G
R
C
TERMINAL
STRIP
G
R
R
G
92
BK
Y1
G
A or AUX
C or X
RC
R or RH
93
O
Factory Wiring
Field Wiring
Control
Wiring
Wire Color Codes
BK = Black
BL = Blue
G = Green
O = Orange
PR = Pirple
R= Red
W = White
Y = Yellow
= Field-Connection Terminal Block (low voltage)
= Terminal Block (low voltage)
Option CL23
Option CL33
•
Electronic, 24 Volt
•
2-stage Heating/Cooling
•
Touch-Screen
Programmable
•
P/N 257338
•
Electronic, 24 Volt
•
2-stage Heating and/or
Cooling
•
Programmable
•
Auxiliary Relay
•
P/N 221038
Wiring Connections - Thermostat Option CL23 or CL33
4. Run the sensor wire to the unit. Use field-supplied 2 to 3 pair of 16 to 22 gauge
wire.
U4
16
GND
Y
Y
DISCHARGE AIR TEMPERATURE SENSOR
(field installed in the supply air duct)
91
O
CONTROL MODULE
Digital control inputs are low-current, resistance-based signals. For optimum
temperature control performance, it is recommended that the sensor inputs (zone
sensors, discharge air sensors, etc.) that are connected to the controller be routed
to the unit in one of the following manners:
• In separate field-supplied conduits, isolated from 24 VAC controls and line
voltage power to the unit,
OR
• If the sensor wires are to be run in the same field-supplied conduit as 24 VAC
control wiring, use shielded cable and bundle wires separately from 24 VAC
control wiring. The shield must be drained at the unit and taped on the opposite
end.
Thermostats
Option CL78
Wiring Connections - Wall-mounted Temperature Monitor, Option CL78
•
Space Mounted, DDC
Temperature Monitor
•
Setpoint Adjustment
•
P/N 272631
GND
RX+/TX+
RX-/TX-
J25
BMS2
SHIELD
RX+/TX+
RX-/TX-
BK
R
BK
R
GND
Option CL78
16
GND
24 V
15
CONTROL MODULE
7.5.3 Field Wiring
by Control Option
(cont’d)
Discharge Air Temperature Sensor (cont’d)
