Form I-Y, P/N 273646R6, Page 4

This system was test operated and inspected at the factory and was in operating

condition. If the equipment has incurred any damage in shipment, document the

damage with the carrier and immediately contact your Reznor

®

distributor.

Check the entire unit for damage paying particular attention to the structural integrity of

the lifting points and the condenser fan section. Check the condenser fan guards and

the fan blades.
On the inside of the control access door, locate the system rating plate (See

FIGURE

2 on page 7, FIGURE 3 on page 8 of FIGURE 4 on page 9). Check the rating plate

information for specifications and the electrical characteristics and verify compatibility

with the installation site.
If installing a unit with a heat section, check the rating plate on the inside of the

heat section door. For a gas heat section, be sure that the rating plate information is

compatible with the altitude and the gas supply at the installation site.

Check for shipped-separate accessories and shipped-loose parts. All systems will

have a shipped-loose discharge air sensor. The roof curb which is shipped separately

(in most cases prior to the unit) requires field assembly. The outside air hood is shipped

with the unit in a separate carton for field assembly and installation. (

NOTE: Install the

hood after the unit is in place. See Paragraph 6.1.)
Listed in the tables below are shipped separately & their availability options.

Standard Efficiency Vertical Flue Discharge Extension Options (pipe not included):

Model No

Option

PN’s Included

Description

H50 & H75

H100, H200,

H300, H400

H102, H125,

H150, H175

H202, H402,

H502, H602 H702 & H802

YDHA, YDMA CC3

235320

(small vent tube)

Single furnace

kit, Metal

Yes

--

--

--

--

YDHA, YDMA,

YDSA

--

Yes

--

--

--

YDHA, YDMA,

YDSA

CC3D 235320

(small vent tube)

Dual furnace

kit, Metal

--

--

Yes

--

--

YDHA, YDMA,
YDSA

235321
(large vent tube)

--

--

--

Yes

--

YDHA, YDMA

--

--

--

--

Yes

High Efficiency Flue Condensate Handling Options:

Model No

Option

PN

Description

G150, G225, G300, G302, G372, G452

G525 & G602

YDHA

FB1

273277

Condensate Frost

Protection

Yes

Yes

YDMA

Yes

Yes

YDSA

Yes

--

YDHA

CSP1

272512

Condensate Pump

Yes

Yes

YDMA

Yes

Yes

YDSA

Yes

--

YDHA

CSN1

272511

Condensate

Neutralizer

Yes

Yes

YDMA

Yes

Yes

YDSA

Yes

--

High Efficiency Vertical Flue Discharge Extension Options (pipe not included):

Model No

Option

PN

Description

G150, G225, G300

G302, G372, G452

G525 & G602

YDHA

CC4

273387

Single furnace

kit, PVC

Yes

--

--

YDMA

Yes

--

--

YDSA

Yes

--

--

YDHA

CC4D

273388

Dual furnace

kit, PVC

--

Yes

Yes

YDMA

--

Yes

Yes

YDSA

--

Yes

--

3.1 Receiving

3.2 Shipped

Separate

Accessories and

Shipped Loose

Parts

3.0 Receiving, Shipped Separate and Storage
