Form I-Y, P/N 273646R6, Page 69
BE18 Dirty Filter Pressure Switch for Main Filters only Factory
BE22 Relay for Remote Exhaust Fan Start/Stop Factory
Option Brief Description Installed
BE28 Dirty Filter Pressure Switch for Main & ER Filters Factory
BHB7 Lon DDC Communication Bus Factory
BHB8 BacNet DDC Communication Bus Fld&Fctry
BP4 High and Low Gas Pressure Switches Factory
BUC3 Duct Pressure Sensor for VVT (Opt D23) Field
CL23
Thermostat, 2-stg Heat/Cool, 24V, Touch Screen
Programmable
Field
CL33
Thermostat, 2-stg Heat/Cool, 24v, Electronic Programmable
with Relay for Damper control
Field
CL78 Space DDC Temperature Monitor w/setpoint adjustment Field
CP__ Disconnect Switch Field
CUF3 Standard Efficiency Single-Speed Condenser Fans Factory
CUF4 High Efficiency Condenser Fans with Speed Control Factory
D19 Space Temperature Control Fld&Fctry
D20 Space Temperature and Humidity Control Fld&Fctry
D21 Make-up Air Control Fld&Fctry
D22 Variable Air Volume Control with Duct Temperature Sensor Fld&Fctry
D23 Variable Air Volume Control with Space Sensor Fld&Fctry
E20 20kw Electric Heat Section Factory
E30 30kw Electric Heat Section Factory
E40 40kw Electric Heat Section Factory
E50 50kw Electric Heat Section Factory
E60 60kw Electric Heat Section Factory
E70 70kw Electric Heat Section Factory
E80 80kw Electric Heat Section Factory
E90 90kw Electric Heat Section Factory
E120 120kw Electric Heat Section Factory
EC90 90kw Electric Heat Section Factory
EC120 120kw Electric Heat Section Factory
EFC1 Power Exhaust Control by Adjustable Constant Volume Factory
EFC4 Power Exhaust Building Pressure Control Fld & Fctry
EFC7 Power Exhaust Control by Supply Fan Tracking with
Adjustable Offset
Factory
EFC9 Power Exhaust Control by Adjustable Constant Volume Factory
EG3 Electric Heat Section 2-4 Stage Control Factory
EG4 Electric Heat Section SCR Modulation Control Factory
ER2A_ Energy Recovery (Total Enthalpy Wheel) Factory
ER2B Energy Recovery (Total Enthalpy Wheel) Factory
ER2C Energy Recovery (Total Enthalpy Wheel) Factory
GF1 External DDC Damper Control (0-10V input signal) Fld&Fctry
Option Brief Description Installed
GF2 DDC Two-Position Damper Control Fld&Fctry
GF4
DDC Four-Position Damper Control based on two input
switches
Fld&Fctry
GF5 DDC Damper Control with Building Pressure Monitor Fld&Fctry
GF8 Economizer Package (CO2 single or dual reference) Fld&Fctry
PE4_ Power Exhaust 0-4000 cfm Fld&Fctry
PE5_ Power Exhaust 0-6000 cfm Fld&Fctry
PE6_ Power Exhaust 0-8000 cfm Fld&Fctry
PH2A 10kw Heater for Energy Wheel Frost Control Factory
PH3A 20kw Heater for Energy Wheel Frost Control Factory
PH4A 30kw Heater for Energy Wheel Frost Control Factory
Option Brief Description Installed
RB5 Wall-mounted Remote Monitoring Display Field
RB6 Hand-held Remote Monitoring Display Field
RPLE Reheat Control - Low Enthalpy Factory
RPHE Reheat Control - High Enthalpy Factory
VFC1
Fan Control by VFD from Adjustable Constant Volume
Control
Factory
VFC2 Fan Control by VFD from External 0-10V Input Signal Fld&Fctry
VFC3
Fan Control by VFD from Duct Static Pressure Sensor (0 to
2.5" iwc)
Fld&Fctry
VFC4
Fan Control by VFD from Building Static Pressure Sensor
Control (-0.5 to 0.5” iwc)
Fld&Fctry
VFC6 Fan Control by VFD from constant SCFM (mass) control Fld&Fctry
VFC9
Fan Control by VFD from Adjustable Constant Volume
Control
Fld&Fctry
Supply Fan Airflow (cfm) / Pressure Drop (iwc) Tables by Fan and Unit Size
Static
Pressure
(iwc)
Supply Fan Airflow (cfm) - by Model and Size Static
Pressure
(iwc)
YDSA YDHA YDMA
120 150 180 210 60 90 120 150 180 210 240 300 360 60 90 120 150 180 210 240 300 360
0.5 --- --- --- --- --- 1025 1025 1025 --- --- --- --- --- --- --- 1025 1025 --- --- --- --- --- 0.5
0.6 --- --- --- --- --- 1123 1123 1123 --- --- --- --- --- --- --- 1123 1123 --- --- --- --- --- 0.6
0.7 --- --- --- --- --- 1213 1213 1213 --- --- --- --- --- --- --- 1213 1213 --- --- --- --- --- 0.7
0.8 --- --- --- --- --- 1297 1297 1297 --- --- --- --- --- --- --- 1297 1297 --- --- --- --- --- 0.8
0.9 --- --- --- --- --- 1376 1376 1376 --- --- --- --- --- --- --- 1376 1376 --- --- --- --- --- 0.9
1.0 1966 1966 --- --- --- 1450 1450 1450 1966 1966 1966 --- --- --- --- 1450 1450 --- 1966 1966 --- --- 1.0
1.2 2154 2154 --- --- --- 1588 1588 1588 2154 2154 2154 --- --- --- --- 1588 1588 1687 2154 2154 --- --- 1.2
1.4 2326 2326 --- --- --- 1716 1716 1716 2326 2326 2326 --- --- --- --- 1716 1716 1822 2326 2326 --- --- 1.4
1.6 2487 2487 --- --- --- 1834 1834 1834 2487 2487 2487 --- --- --- --- 1834 1834 1948 2487 2487 --- --- 1.6
1.8 2638 2638 --- --- 621 1945 1945 1945 2638 2638 2638 --- --- 621 621 1945 1945 2066 2638 2638 --- --- 1.8
2.0 2780 2780 --- --- 655 2051 2051 2051 2780 2780 2780 --- --- 655 655 2051 2051 2178 2780 2780 --- --- 2.0
2.2 2916 2916 --- --- 687 2151 2151 2151 2916 2916 2916 --- --- 687 687 2151 2151 2284 2916 2916 --- --- 2.2
2.4 3046 3046 --- --- 717 2246 2246 2246 3046 3046 3046 --- --- 717 717 2246 2246 2386 3046 3046 --- --- 2.4
2.6 3170 3170 --- --- 747 2338 2338 2338 3170 3170 3170 --- --- 747 747 2338 2338 2483 3170 3170 --- --- 2.6
2.8 3290 3290 --- --- 775 2426 2426 2426 3290 3290 3290 --- --- 775 775 2426 2426 2577 3290 3290 --- --- 2.8
3.0 3405 3405 --- --- 802 2511 2511 2511 3405 3405 3405 --- --- 802 802 2511 2511 2667 3405 3405 --- --- 3.0
3.2 3517 3517 --- --- 828 2594 2594 2594 3517 3517 3517 --- --- 828 828 2594 2594 2755 3517 3517 --- --- 3.2
3.4 3625 3625 --- --- 854 2674 2674 2674 3625 3625 3625 --- --- 854 854 2674 2674 2840 3625 3625 --- --- 3.4
3.6 3730 3730 --- --- 878 2751 2751 2751 3730 3730 3730 --- --- 878 878 2751 2751 2922 3730 3730 --- --- 3.6
3.8 3832 3832 --- --- 903 2827 2827 2827 3832 3832 3832 --- --- 903 903 2827 2827 3002 3832 3832 --- --- 3.8
Wiring Diagram Option Identification (cont’d)
Appendix (cont’d)
