Potter PFC-6030 User Manual
Page 96
5-90
PFC-6030 • 5403595 • Rev C • 2/13
To add and configure a DACT module:
Select
1.
Dialer from the system panel.
Click the
2.
Add Device button. The “Add Dialer” window displays.
Example of Add Dialer Window
Figure 130.
In the
3.
“Phone Line 1 and Phone Line 2” fields, make any necessary changes.
Example of Phone Lines Options
Figure 131.
enter the
y
number of rings you want the DACT to pickup when receiving a call.
Note: If you do not change the default from "0", the DACT will never pick up a call!
enter the appropriate line prefix, if any is required for your phone lines.
y
Example: In the example shown above, the phone line requires that "9" is dialed to get an outside line.
The two ",," (commas) instruct the dialer to pause 2 seconds before dialing the reporting account numbers.
In the
4.
“Reporting Accounts” section, make the necessary selections for the primary and secondary reporting accounts:
Select the
y
Report type(s): Alarms, Troubles, Supervisory
enter the A
y
ccounts IDs and Phone Numbers
Select the
y
Primary Report By option: Panel, Zone or Point
Choose the
y
Primary Format option: CID / SIA
Note: Both SIA-DCS and Ademco Contact ID protocols are supported.
Example of Report Accounts Setup
Figure 132.
The "Primary" account setting
fields are displayed here.
Each "," (comma) creates
a 1-second pause before
the dialer attempts to dial a
reporting account number.
