1-2
PFC-6030 • 5403595 • Rev C • 2/13
PSN-1000 / PSN-1000(e) Intelligent Power Supply expander – An accessory to the panel providing ten (10) amps of y y
additional power, with four (4) input points, six (6) notification circuits and a P-Link interface
LeD-16 Annunciator module - Maximum of 10 total per system (
y y the total may be any combination of LED-16 and
DRV-50 LED modules) allows for up to 16 zones alarm, supervisory and trouble conditions to display, and 5 non-
programmable system LeDs that display system's overall condition
DRv-50 LeD Driver module - Maximum of 10 total per system (
y y the total may be any combination of LED-16 and DRV-50
LED modules) allows output to up to 50 LeDs, 4 dry contact inputs, and 5 non-programmable system LeDs that display
system's overall condition
RLY-5 Relay Board module - Maximum of 31 per system provides five (5) Form-C relay outputs
y y
FCB-1000 Fire Communications Bridge - An accessory that provides a remotely-located IP connection to the panel y y
FIB-1000 Fiber Interface Bridge - An accessory to the panel that converts the standard 4-wire P-Link bus to and from optic y y
cable capable of Class A operation; maximum of 31 per system
SPG-1000 Serial Parallel Gateway - An accessory to the panel that allows a serial or parallel printer connection; up to 31
y y
maximum per system
SLC Loop Accessories
Addressable Sensors •
Photoelectric Smoke Detector (PSA) y
Photoelectric/Heat Smoke Detector (PSHA) y
Fixed Temperature Heat Detector (FHA) y
Rate of Rise/Fixed Temperature Heat Detector (RHA) y
Addressable Isolator Base (AIB) y
Addressable Relay Base (ARB) y
Addressable Sounder Base (ASB) y
Addressable Pull Station (APS) y
Addressable Modules •
Miniature Contact Module (MCM) y
Single Contact Module (SCM-4) y
Dual Contact Module (DCM-4) y
Twin Relay Module (TRM-4) y
Monitored Output Module (MOM-4) y
Conventional Input Zone Module (CIZM-4) y
Short Circuit Isolator (SCI) y
How to Use this Manual
Refer to this manual before contacting Technical Support. The information in this manual is the key to a successful installation and
will assist you in understanding proper wire routing, system requirements, and other guidelines specific to the PFC-6030 system.
Common Terminology
The following table provides you with a list of terms and definitions used with the PFC-6030 system:
Terminology Table 1:
Term Definition
PFC-6030 Cabinet Enclosure
eOLD or Diode Assembly end of Line Diode Assembly
EOLR end of Line Resistor Assembly
Remote Annunicator LCD type Remote Annunicator
NAC Notification Appliance Circuit
SLC Signaling Line Circuit
DACT Digital Alarm Communicator Transmitter (UD-1000)
