A-1
PFC-6030 • 5403595 • Rev C • 2/13
Appendix A: Basic Operating Instructions
These instructions must be framed and displayed next to the PFC-6030 panel in accordance with NFPA 72 fire code for Local
Protected Fire Alarm Systems. Test the system in accordance to NFPA 72.
Button Functions Table 23:
Button Function
ACK
Arrows
Drill
Esc
Reset
Silence
Operating Instructions Table 24:
Operation Task
Silence Alarms, Troubles Press the SILENCE pushbutton.
Acknowledge Alarms,
Troubles
Press the ACK pushbutton.
Reset Alarms Press the RESET pushbutton.
view Alarms, Troubles Press arrows to view alarms / troubles.
Conduct a Fire Drill Press the DRILL pushbutton; press the RESET button to exit Drill mode.
view Point’s Status
Press •y ENTER to display the Main Menu.
Press •y 5 – System Tools; enter panel’s code.
Press •y 2 – Point Control.
Scroll •y Up/Down to choose Internal SLC / PWR, and press ENTER.
Enter •y Addr / Ckt No. and press ENTER.
Press •y Up/Down to view previous / next points.
Check Detector Sensitivity
Press •y ENTER to display the Main Menu.
Press •y 5 – System Tools; enter panel’s code.
Press •y 1 – SLC Tools.
Press •y 1 – SLC Pinpoint.
Enter •y Addr #, press ENTER; detector address and type displays.
Press •y ENTER to display current usage.
Press •y Up to display Day/Night Sensitivity settings.
Press •y Up / Down to scroll through point’s day / night sensitivity settings.
