3-21
PFC-6030 • 5403595 • Rev C • 2/13
For a Single Device:
From the 1. SLC Addr Prog menu, press 1 to address a Single device.
Attach connector wires to 2. SLC PGM terminals, if not already done. The “Connect Device” prompt displays.
Connect device. 3. The “Found Address: xx” prompt displays.
Modify new address, if needed, or press y y ENTER to continue.
The y y “Writing Addr: XX” prompt displays, and the system beeps three (3) times when completed.
When addressing is completed, the “Found Addr: XX, New Addr: XX” prompt displays.
Disconnect device, and continue with next device. y y
Repeat steps, as needed. y y
Press
4. ESC when finished.
For Multiple Devices:
From the 1. SLC Addr Prog menu, press 2 to address Mult device.
The “ •y Start Address: XX” prompt displays.
Modify starting address, if needed, and press •y ENTER.
The prompt •y “Connect Device” displays.
Connect 1 2. st device. The “Addr = XX Next = XX Remove” prompt displays.
Disconnect the device, connect next device. Addressing is completed when the panel emits a series of •y three (3) beeps.
The •y “Addr = XX Next = XX Remove” prompt displays.
Continue with next device, following prompts. •y
Notes:
The prompt •y “Addr = XX” refers to the current device number, and “Next = XX” is the next sequential address number.
When configuring a •y Class B DCM-4, press the UP ARROW to skip the next sequential number. The Class B DCM-4
requires 2 addresses; if this isn't done, the next available address will be assigned to a different device and the DCM-4
will operate as a single point device.
Press 3. ESC when finished.
