5-73
PFC-6030 • 5403595 • Rev C • 2/13
Zone Attributes Table 17:
Attribute Description
Output Pattern
Default = Constant
Defines the output pattern of general-purpose NAC circuits in the zone that •y
occurs during alarm conditions.
Click on drop-down arrow to display and select an option:
•y
Constant 24VDC
ANSI .5 sec on, .5 sec off, .5 sec on, .5 sec off, 5 sec on, 1.5 sec off
March Code 60 signals per minute
Double Time 120 signals per minute
Day Sensitivity
Default = 3.5%
Range: 1.1% – 3.5%
The 3.5% default represents the percentage of obscuration per foot for all smoke
sensing detectors.
The term “ •y obscuration” refers to the amount of reduction in air transparency
caused by smoke.
Day sensitivity is functional during the time a building is normally occupied. •y
Night Sensitivity
Default = 2.5%
Range: 1.1% – 3.5%
The 2.5% default represents the percentage of obscuration per foot for all smoke
sensing detectors.
The term “ •y obscuration” refers to the amount of reduction in air transparency
caused by smoke.
Night sensitivity is functional during the times the building is unoccupied, •y
i.e., weekends, Holidays.
Heat Sensitivity
Default = 135̊F
Range: 135̊F – 185̊F
Sets alarm threshold for Fix Temperature Heat Detectors (FHA).
Fixed/ROR Heat Sensitivity
and 15̊ increase in 1 minute
Default = 135̊F
Range: 135̊F – 174̊F
Sets alarm threshold for Fixed/ROR Heat Sensor (RHA).
Auto-Silence Timer
Default = 0 minutes
Range = 0 – 360 minutes
Defines the amount of time before silenceable NACs are automatically shut down.
Auto-Unsilence Timer
Default = 0 minutes
Range = 0 – 60 minutes
Defines the amount of time before any silenced NACs are reactivated; outputs
only reactivate if panel is still in alarm.
Silence-Inhibit Timer
Default = 0 minutes
Range = 0 – 60 minutes
Defines the amount of time you may not silence an output when in alarm.
Restore Delay
Default = 0 minutes
Range = 0 – 300 seconds
Defines the amount of time before deactivating an output when the panel is reset.
