Potter PFC-6030 User Manual
Page 88
5-82
PFC-6030 • 5403595 • Rev C • 2/13
Group by Area
You may group information by different fields in many of the program windows. This flexibility is helpful when configuring or
viewing a large amount of information, such as all devices, zones or remote annunciators. examples are included for illustration
purposes only.
To group by area (field):
Click on “
1.
group bar” located at top of window, if available.
Example of Group Bar in Points Window
Figure 113.
The
2.
“group by area” region displays, as shown.
Group by Area Field
Figure 114.
Note: Click on “group bar” at any time to collapse region.
Drag and drop one field into the
3.
“group by area” region. The information displays grouped by selected field.
Example of Points Grouped by Function
Figure 115.
Click
4.
“+” next to the function to view a complete list of points. Click “-” to collapse list of points, as needed.
Example of Points Configured as Addr Detector Photo
Figure 116.
Drag field out of
5.
“group by area” region to redisplay items in original order.
