Main Board Wiring Specifications
There are several wiring requirements to consider before connecting circuits to the main board: (1) the circuit separation,
and (2) wiring types.
Circuit Separation
Proper separation between the different types of circuits must be maintained between Power Limited, Non-Power Limited, and
High voltage wiring to reduce electrical interferences, transient voltage or voltage ratings.
Separations between the different wiring types y y must be maintained by at least ¼ inch and the wire insulation must be for the
higher voltage.
The control panel cabinet has sufficient knockouts located around the periphery allowing the installer to maintain separation y y
between power limited and non-power limited connections.
Wiring Types
Wiring specifications must be followed to prevent damage or other consequences.
Refer to table below for a breakout of the different wiring requirements shown by circuit type:
Main Board Circuit Wiring Types Table 5:
Wiring Type
Type of Circuit Voltage Power
AC Connection High voltage Non-Power Limited
Battery Connection Low voltage Non-Power Limited
Trouble Relay Low voltage Non-Power Limited
Supervisory Relay Low voltage Non-Power Limited
Alarm Relay Low voltage Non-Power Limited
I/O Circuits Low voltage Power Limited
Notification Device Circuits (NACs) Low voltage Power Limited
P-Link RS-485 Connections Low voltage Power Limited
Signaling Line Circuit Low voltage Power Limited
Phone Line – DACT High voltage Non-Power Limited
