If switchback is enabled, a processor running under power-management mode automatically clears the PMME bit to
0 and returns to normal mode when any of the following conditions occur:
• An external interrupt condition occurs on an INTn pin and the corresponding external interrupt is enabled.
• An active-low transition occurs on the USART serial receive input line (modes 1, 2, and 3) and data reception is
enabled .
• The SBUF register is written to send an outgoing byte through the USART and transmission is enabled .
• The SPIB register is written in master mode (STBY = 1) to send an outgoing character through the SPI module and
transmission is enabled .
• The SPI module’s SSEL signal is asserted in slave mode .
• Active debug mode is entered either by breakpoint match or issuance of the debug command from background
mode .
• Power-fail interrupt if enabled (PFIE = 1).
2.13 Stop Mode
When the MAXQ612/MAXQ622 are in stop mode, the CPU system clock is stopped and all processing activity is halted .
All on-chip peripherals requiring the system clock are also stopped . Power consumption in the lowest power stop mode
is basically limited to static leakage current .
Stop mode is entered by setting the STOP bit to 1 . The processor enters stop mode immediately once the instruction
that sets the STOP bit is executed .
Note: It is necessary to include a ‘nop’ immediately following the instruction to invoke stop mode for proper interrupt
operation . Example code is as follows:
move ckcn, #010h ; enter stop mode
nop ; No operation to cause a one cycle delay
The MAXQ612/MAXQ622 exit stop mode when any of the following conditions occur:
• An external interrupt condition occurs on one of the INTn pins and the corresponding external interrupt is enabled.
After the interrupt returns, execution resumes after the stop point .
• An external reset signal is applied to the RESET pin . After the reset signal is removed, execution resumes from utility
ROM at 8000h as it would after any reset state .
• A power-fail interrupt occurs, if enabled (PFIE = 1).
• A wake-up timer interrupt occurs, if enabled (WTE = 1) .
Note that the voltage monitor and bandgap reference can be disabled during stop mode to conserve current con-
sumption . In this case, a power-fail condition does not cause a reset as it would under normal conditions . However,
the POR monitor remains enabled, and any voltage drop on V
DD that goes below the POR level causes a POR to
occur . To continue to monitor supply voltage during stop mode, the power-fail monitor is left on if the regulator is left
on (REGEN = 1), or it can be explicitly enabled (if the regulator is disabled; REGEN = 0) by clearing the PWCN .PFD bit
to 0 . The power-fail monitor is always enabled prior to stop mode exit and resumption of code execution .
Once the processor exits stop mode, it resumes execution as follows:
• If the crystal oscillator is selected as the system clock source, the crystal oscillator is started and execution resumes
following an 8192-clock-cycle delay to allow the oscillator frequency to stabilize .
