The host now can transmit and receive serial data through the 10-bit data shift register that exists between the TDI
input and TDO output during DR-scan sequences . All background and debug mode communication (commands, data
input/output, and status) occurs through this serial channel . Each 10-bit exchange of data between the host and the
MAXQ612/MAXQ622 internal hardware is composed of two status bits and a single byte of command or data .
The 10-bit word is always transmitted least significant bit first with the format shown below .
The data byte portion of the 10-bit shift register is interfaced directly to the ICDB parallel register . The ICDB register
functions as the holding data register for both transmit and receive operations . On the falling edge of TCK in the
update-DR state, the outgoing data is loaded from the ICDB parallel register to the debug shift register and the incom-
ing shift register data is latched in the ICDB parallel register .
14.1 Background Mode Operation
When the instruction register is loaded with the debug instruction (IR[2:0] = 010b), the host can communicate with
the MAXQ612/MAXQ622 microcontrollers in a background mode using TAP DR-scan sequences without disturbing
CPU operation . Note, however, that JTAG in-system programming also requires use of the 10-bit debug shift register
and, if enabled (SPE, PSS[1:0] = 100b), takes precedence over background mode communication . When operating in
background mode, the status bits are always cleared to 00b (nondebug), which indicates that the MAXQ612/MAXQ622
microcontrollers are ready to receive background mode commands .
The host can perform the following operations from background mode:
• Read/write internal breakpoint registers (BP0 to BP5)
• Read/write internal in-circuit debug registers (ICDC, ICDF, ICDA, ICDD)
• Monitor to determine when a breakpoint match has occurred
• Directly invoke debug mode
The background mode commands supported by the MAXQ612/MAXQ622 microcontrollers are shown in Table 14-1 .
Encodings not listed in this table are not supported in background mode and are treated as no operations .
TDI TDO
MAXQ612
MAXQ622
x x
0 9 0 9
HOST COMMAND/DATA INPUT MAXQ612/MAXQ622 DATA OUTPUT
s[1:0]
00 NONDEBUG. DEFAULT CONDITION,
BACKGROUND MODE, OR DEBUG ENGINE
INACTIVE.
01 DEBUG IDLE. DEBUG ENGINE IS READY TO
RECEIVE DATA FROM THE HOST (COMMAND, DATA).
10 DEBUG BUSY. DEBUG ENGINE IS BUSY WITHOUT
VALID DATA (i.e., ROM CODE EXECUTION, TRADE
OPERATIONS).
11 DEBUG VALID. DEBUG ENGINE IS BUSY WITH
VALID DATA.
STATUS CONDITION
