MAXQ612/MAXQ622 User’s Guide
2-28 Maxim Integrated
Table 2-8. Interrupt Priority
*With the exception of the power-fail interrupt, all interrupts require that the IGE bit be set to 1 to generate an interrupt request,
regardless of the individual interrupt enable listed. The power-fail interrupt is not governed by IGE (i.e., interrupt request genera-
tion is controlled solely by the PFIE enable bit).
INTERRUPT
VECTOR
ADDRESS
(HEX)
NATURAL
PRIORITY
FLAG ENABLE* PRIORITY CONTROL
Power Fail 20h 0 PFI (PWCN .2) PFIE (PWCN .1) IVP0[1:0] (IPR0[1:0])
Memory Fault 28h 1
PULRF (IC .4),
PULWF (IC .5),
PSYRF (IC .6),
PSYWF (IC .7)
MPE (SC .10) IVP1[1:0] (IPR0[3:2])
External INT[7:0] 30h 2 IE[7:0] (EIF0) EX[7:0] (EIE0) IVP2[1:0] (IPR0[5:4])
IR Timer 38h 3
IROV (IRCNB .0),
IRIF (IRCNB .1)
IRIE (IRCNB .2) IVP3[1:0] (IPR0[7:6])
Serial Port 0
40h 4
RI (SCON0 .0),
TI (SCON0 .1)
ESI (SMD0 .2)
IVP4[1:0] (IPR0[9:8])
Serial Port 1
RI (SCON1 .0),
TI (SCON1 .1)
ESI (SMD1 .2)
SPI 0
48h 5
MODF (SPICN0 .3),
WCOL (SPICN0 .4),
ROVR (SPICN0 .5),
SPIC (SPICN0 .6)
ESPII (SPICF .7)
IVP5[1:0] (IPR0[11:10])
External INT[15:8] IE[15:8] (EIF1) EX15[7:8] (EIE1)
Timer B0
50h 6
TFB (TBOCN .7),
EXFB (TB0CN .6)
ETB (TB0CN .1)
IVP6[1:0] (IPR0[13:12])
Timer B1
TFB (TB1CN .7),
EXFB (TB1CN .6)
ETB (TB1CN .1)
Wake-Up Timer
58h 7
WTF (WUTC .1) WTE (WUTC .0)
IVP7[1:0] (IPR0[15:14])
Watchdog Timer WDIF (WDCN .3) EWDI (WDCN .6)
USB 60h 8
USBINT .7:0,
EPINT .7:0
USBIE .7:0, EPIEN .7:0 IPR1[1:0]
I 2 C 68h 9 I2CST .11:0 I2CIE[11:0] IPR1[3:2]
SPI 1 70h 10
MODF (SPICN1 .3),
WCOL (SPICN1 .4),
ROVR (SPICN1 .5),
SPIC (SPICN1 .6)
ESPII (SPICF .7) IPR1[5:4]
Reserved 78h 11 — — IPR1[7:6]
Reserved 80h 12 — — IPR1[9:8]
Reserved 88h 13 — — IPR1[11:10]
Reserved 90h 14 — — IPR1[13:12]
Reserved 98h 15 — — IPR1[15:14]
