NS2503-24P/2C User Manual

HTTP Firmware Upgrade

The HTTP Firmware Upgrade page contains fields for downloading system image files from the Local File browser to the
device. The Web Firmware Upgrade screen in

Figure 4-2-17

appears.

Figure 4-2-17:

HTTP Firmware Upgrade Interface Screenshot

To open Firmware Upgrade screen perform the following:
1.

Click System -> Web Firmware Upgrade.

The Firmware Upgrade screen is displayed as in

Figure 4-2-18.

3. Click

the

“Browse”

button of the main page, the system would pop up the file selection menu to choose firmware.

Figure 4-2-18:

Firmware Location Screenshot

Select on the firmware then click “Upload”, the Software Upload Progress would show the file upload status.

Firmware upgrade needs several minutes. Please wait a while, and then manually
refresh the webpage.
