NS2503-24P/2C User Manual

143

CONSOLE MANAGEMENT


The Managed Switch is equipped with a RS-232 DB9 connector as default. And support telnet management.

Login in the Console Interface

To configure the system via console mode, connect a serial cable to a COM port on a PC or notebook computer and to RJ-45
type serial (console) port of the Managed Switch. The console port of the Managed Switch is DCE already, so that you can
connect the console port directly through PC without the need of Null Modem.

Please refer to

chapter 3.5- Administration Console

to get more information about how to connect to the console interface of

Managed Switch with HyperTerminal on Microsoft Windows platform.

Once the terminal has connected to the device, power on the Managed Switch, the terminal will display that it is running testing
procedures.

Then, the following message asks the login password. The factory default password as following and the login screen in

Figure

5-1

appears.

Username: admin
Password: admin

Figure 5-1:

Managed Switch Console Login Screenshot

1.

For security reason, please change and memorize the new username and password after this
first setup.

Username Max: 6, Min: 1 characters.
Password Max: 6, Min: 1 characters.

2.

Only accept command in lowercase letter under console interface.
