The page includes the following fields:
Object Description
System PoE Admin Mode
Allows user enable or disable PoE function. It enables or disables the power
on all of the PoE ports.
PoE PSU Status
Display current PoE power supply working status.
PoE Temperature Unit 1
Display the current operating temperature of PoE chip unit 1.
The unit 1 is in charge of PoE Port-1~Port-12
PoE Temperature Unit 2
Display the current operating temperature of PoE chip unit 2.
The unit 1 is in charge of PoE Port-13~Port-24
Temperature Threshold Allows setting over temperature protection threshold value. If the system
temperature was over the value then system lowers the total PoE power
budget automatically.
Over Temperature Protection
Enabled to prevent system damage dut to overheating. When POE unit
temperature rises over the Temperature Threshold value, PoE power budget
will be reduced 20 watts when the temperature raised 3 Degree C each time,
and PoE power budget will going down 60 watts maximum.
For example, 360 watts is default PoE power budget and Temperature
Threshold is 50 Degree C, PoE temperature raise is going to cause PoE
Power budget changing as follow.
PoE Unit Temperature PoE Power Budget
50 360 watts
51 340 watts
54 320 watts
57 300 watts
Power limit mode Allow to configure power limit mode of Web Smart Device. It can choose :
 Consumption Detect the real power from the PDs.
 Classification Deliver PoE power by port priority setting and device
PoE power level.
PoE Usage Threshold Allows setting how much PoE power budget could be limited.
Power Allocation Show the total watts usage of PoE Switch.
PoE Function Can enable or disable the PoE function.
PoE Schedule Allows user set the PoE port enable or disable according to PoE Schedule
profile. This function must co-work with SNTP function.
Power Mode Displays per port PoE operate status, 802.3af or 802.3at.
Priority Set port priority for the POE power management
It works on the “Classification” power limit mode only, value is :
 Critical
 High
 Low
High priority is “Critical”.
