NS2503-24P/2C User Manual

108

The page includes the following fields:

Object

Description

Priority

The bridge identifier of the root bridge. It is made up from the bridge priority and
the base MAC address of the bridge.

MAC Address

The bridge identifier of the root bridge. It is made up from the bridge priority and
the base MAC address of the bridge.

Root Path Cost

For the Root Bridge this is zero. For all other Bridges, it is the sum of the Port
Path Costs on the least cost path to the Root Bridge.

Root Port

The switch port currently assigned the root port role.

Maximum Age

Path Cost to the Designated Root for the Root Bridge.

Hello Time

Minimum time between transmissions of Configuration BPDUs.

Forward Delay

Derived value of the Root Port Bridge Forward Delay parameter.
