Fs-n11c□/n12c□/n13cp/n14cp – KEYENCE FS-N10 Series User Manual
Page 95
5-3 Dimensions
5
Sp
eci
fic
at
io
ns
5-9
- Digital Fiber Sensor FS-N10 Series User's Manual -
FS-N11C
/N12C
/N13CP/N14CP
* 1 FS-N11CN(P)/N13CP/ is not provided with an expansion connector.
8.6
M8 connector
3.4
20.7
35.4
71.8
22.9
2
2
3.4
3.4
7.2
6.4
4.4
25.7
15
31
25.4
9.5
(35.3)
6.7
4
30.3
(15.5)
(38.5)
(18.8)
30.3
3.8
6.5
9.8
9.8
When co
v
er is opened:
100 max.
Max. 170°
When amplifier mounting bracket (OP-73880) is used
Bottom surface of amplifier mounting bracket
Counterbore:
Depth:3.2
Counterbore:
Depth:2.7
