6-9 - Digital Fiber Sensor FS-N10 Series User's Manual -
6
6-4
Restrictions on Each Detection Mode
The sensitivity setting is limited according to the selected detection mode.
Refer to the chart below for details.
 Reading the table
(Example) When detection mode is set to dtM1 (DATUM1 mode)
When the sensitivity setting is set to Std , two-point calibration, maximum
sensitivity calibration and full auto calibration are enabled.
Positioning calibration, preset function and zero shift function operations
are disabled.
Refer to page 4-4 for details of "Sensitivity Setting" and page 4-8 for details of
"Detection Mode".
*1 Items which are indicated as × for the sensitivity setting will operate with Std
calibration.
*2 In the edge detection mode, the bar display, even if SEtP / OSEt is selected for the
sensitivity setting, the mode will function as edge detection calibration.
*3 Positioning calibration is not possible in the DATUM1 or DATUM2 modes. This
will operate as two-point calibration.
*4 If the [PRESET] button is pressed in the DATUM1/DATUM2 mode, the received
light intensity will be forcibly calibrated to
100.0 / .0 . " ---- ---- " appears and no
change is seen when the [PRESET] button is pressed in the edge detection
mode.
*5 The zero shift operation does not function when the DATUM1/DATUM2 or edge
detection mode is selected.
Restrictions for Sensitivity Settings in Each Detection Mode
Sensitivity setting
*1
Preset
function *4
Zero shift
calibration *5
Std (Standard)
SEtP
(Percentage
calibration)
0SEt
(Zero shift
calibration)
two-point
calibration
Maximum
sensitivity
calibration
Full auto
calibration
Positioning
calibration
*3
Edge
detection
*2
Det
ect
io
n mode
Std
   
×
   
DtM1    Ч Ч  Ч Ч Ч
DtM2    Ч Ч  Ч Ч Ч
Area     Ч  Ч  
_|~d Ч Ч Ч Ч

Ч Ч Ч Ч
~L_d Ч Ч Ч Ч

Ч Ч Ч Ч
