4-4 Display Settings (diSP)
4
Set
tings
f
o
r
Ad
v
an
ced F
u
nct
ion
s
4-28
- Digital Fiber Sensor FS-N10 Series User's Manual -
The saturation level can be set in the range of
100P
(100%) to
200P
(200%) when the
preset saturation function is ON.
For example, if this function is set to 150P, the received light intensity will be corrected
to "
150.0
" when the preset function is enabled, and the digital display will display
"
100.0
".
The saturation level can be set to a higher value for stable detection even in
environments which are prone to some contamination, such as dust.
Turn off this function if you want to display values above "
100.0
" in applications where
the preset function or the DATUM1 mode is used.
Setting too high of a saturation level (specifying too large a value)
decreases the detectability for small differences in light intensity or
transparent workpieces.
*1
When the detection mode is set to DATUM1, the preset saturation function ON/
OFF state can be selected, but the saturation level will be fixed to 101P (101%),
and the setting screen will not appear.
*2
When the detection mode is set to DATUM2, the preset saturation function set-
ting screen will not appear.
• For the preset execution method, refer to
• Refer to the next page for the detailed operating principle.
Preset Saturation Function
Refer to page 4-2 "Display Settings (diSP)" for setting methods.
Display
Function
on
(ON)
Fixes the display to "
100.0
" (displays no value higher than "
100.0
")
when the actual received light intensity is above 100.0. (Default:
110P
)
oFF
(OFF)
Displays the actual received light intensity as is, even when it is
above "
100.0
".
Point
Reference
