4-3 Detection Settings (Func)
4
Set
tings
f
o
r
Ad
v
an
ced F
u
nct
ion
s
4-15
- Digital Fiber Sensor FS-N10 Series User's Manual -
Methods for setting upper and lower limits
The upper and lower limits can be set using one of the 2 methods:
Setting sensitivity using the percentage calibration mode
Sensitivity setting using other calibration modes
Sensitivity is set separately for Hi and Lo.
1
Press
to display "
Hi
" or "
Lo
".
The "
Hi
" or "
Lo
" value, and the current set-
ting values are displayed alternately.
When the [MODE] button is pressed while
the display alternately flashes, the "
Hi
" or
"
Lo
" display changes.
If you do nothing for 3 seconds or more,
the received light intensity display is auto-
matically restored.
2
Press the [SET] button to perform sen-
sitivity setting (two-point calibration,
maximum sensitivity setting, or other).
Calibration is complete after the setting
value flashes momentarily, and then stops
(lights up).
