Page 50: Basic settings -4, Power modes -4 sensitivity setting -4, Basic settings

4
Set
tings
f
o
r
Ad
v
an
ced F
u
nct
ion
s
4-4
- Digital Fiber Sensor FS-N10 Series User's Manual -
4-2
Basic Settings
The detection stability will increase when the response time is delayed.
You can select from the following 6 power modes.
The response time slows down in the order of
hSP
,
FinE
,
turb
,
Supr
,
ULtr
,
MEGA
.
Detection distance varies depending on the fiber units to be combined. For specific
numerical values, refer to the catalogues and specifications of the fiber units
concerned.
When using the unit in point-blank range, raising the power mode exces-
sively may attenuate the received light intensity. In such a case, either
lower the power mode or use the saturation Canceling function.
"Light emission/Received light intensity adjustment (Saturation
You can select from the following 3 sensitivity setting methods.
*
Refer to the following 2 pages for details.
Power Modes
Refer to page 4-2 "Basic Settings" for setting methods.
Display
Power mode name
Response time
hSP
HIGH SPEED mode
50 µs
FinE
FINE mode (Default)
250 µs
turb
TURBO mode
500 µs
SuPr
SUPER mode
1 ms
ULtr
ULTRA mode
4 ms
MEGA
MEGA mode
16 ms
Point
Sensitivity Setting
Refer to page 4-2 "Basic Settings" for setting methods.
Display
Sensitivity setting method
Reference
page
Std
Normal sensitivity setting (without correction) (Default)
SEtP
Percentage calibration
0SEt
Zero shift calibration
