Checkline FH Series User Manual

Page 54

1 set precision standards for sensor FH 4 for multi-point calibration for 1.5 mm dia.

target ball size, comprising:

1 precision standard set for approx. 0.15 mm, 0.25 mm, 0.43 mm, 0.75 mm and

1.3 mm

82-174-0010

1 set precision standards for sensor FH4 for multi-point calibration for 2.5 mm

target ball size, comprising:

1 precision standard set for approx. 0.25 mm, 0.43 mm, 0.75 mm, 1.3 mm and

2.2mm (1 pc each)

82-174-0011

1 set precision standards for sensor FH4 for multi-point calibration for 4,0 mm

target ball size, comprising:

1 precision standard set for approx. 0.43 mm, 0.75 mm, 1.3 mm, 2.2 mm and

3.6mm ( 1 pc each)

82-174-0012

1 set of target balls, 1.5 mm dia. (100 pcs)

82-174-0004

1 set of target balls, 2.5 mm dia. (100 pcs)

82-175-0004

1 set of target balls, 4 mm dia. (50 pcs)

82-175-0005

Manufacturer’s Test Certificate according to DIN 55350 M for precision standards

Manufacturer’s Test Certificate according to DIN 55350 M for 1 set precision

standards for multi-point calibration

Accessories for sensor FH10

Sensor stand, spring-loaded, for s Sensor FH 10 (incl. in standard delivery)

70-175-0014

Zero calibration standard for FH 10 sensor 2. 5 mm dia. target ball (standard
delivery)

82-175-0033

Zero calibration standard for FH 10 sensor 4 mm dia. target ball (standard
delivery)

82-175-0034

Zero calibration standard for FH 10 sensor 6 mm dia. target ball (standard
delivery)

82-175-0035

Zero calibration standard for FH 10 sensor 9 mm dia. target ball (standard
delivery)

82-175--0036

Precision standard for sensor FH10 1 mm (standard delivery)

82-175-0030

Precision standard for sensor FH10 3 mm (standard delivery)

82-175-0031

Precision standard for sensor FH10 8 mm (standard delivery)

82-175-0032

1 basic calibration set for sensor FH10 for target ball dia. 9.0 mm, comprising:
Zero calibration standard, and 10 pcs target balls 9 mm dia., comes in a plastics
box

82-175-0038

1 set precision standards for sensor FH10 for multi-point calibration for target ball
dia. 2.5 mm, comprising:
1 set precision standards approx. 0.25 mm, 0.43 mm, 0.75 mm, 1.3 mm and
2.2mm

82-175-0020
