14. Technical specification
14.1 Gauge and Sensor Specification
Measuring principle:
magneto-static principle, suitable for nonmagnetic materials
Measuring rate: 20 readings per second (factory set)
Number of readings to be logged
for statistics: 1, 2, 5, 10 or 20 readings per second (user adjustable)
Sensor types: FH4 FH10
Low range resolution: 0.1 µm 0.2µm
Display resolution Ranges Resolution:
0.0 µm – 59.9 µm
60.0 µm – 149.9 µm
150.0 µm – 299.5 µm
300.0 µm – 599.0 µm
600.0 µm – 998.0 µm
1.000 mm – 1.498 mm
1.500 mm – 2.995 mm
3.00 mm – 5.99 mm
6.00 mm – 10.12 mm
0.1 µm
0.2 µm
0.5 µm
1 µm
2 µm
2 µm
5 µm
10 µm
20 µm
FH4 Sensor
Tolerance:
Target ball Ø
Measuring
range
Reproducibility Factory
calibration:
Zero-point
calibration
Multi-point
calibration
1.5 mm 0 ... 1.5 mm ± (1.5 µm + 0.5%)* ± (10 µm + 3%)* ± (5µm + 1.5%)* ± (3µm + 1%)*
2.5 mm 0 ... 2.5 mm ± (2.5 µm + 0.5%)* ± (15 µm + 3%)* ± (8µm + 1.5%)* ± (5µm + 1%)*
4.0 mm 0 ... 4.0 mm ± (5 µm + 0.5%)* ± (30 µm + 3%)* ± (15µm + 1.5%)* ± (10µm + 1%)*
FH10 Sensor
Tolerance:
Target ball Ø
Measuring
range
Reproducibility Factory
calibration:
Zero-point
calibration
Multi-point
calibration
2.5 mm 0 ... 2.5 mm ± (2.5 µm + 0.5%)* ± (15µm + 3%)* ± (8µm + 1.5%)* ± (5µm + 1%)*
4.0 mm 0 ... 4.0 mm ± (5 µm + 0.5%)* ± (30µm + 3%)* ± (15µm + 1.5%)* ± (10µm + 1%)*
0 ... 6 mm ± (10 µm + 0.5%)* ± (50µm + 3%)* ± (30µm + 1.5%)* ± (20µm + 1%)*
6.0 mm
6 ... 10 mm ± 0.5%* ± 4%* ± 2.5%* ± 1.5%*
9.0 mm 0 ... 10 mm ± (10 µm + 0.5%) * ± (50µm + 3%)* ± (30µm + 1.5%)* ± (20µm + 1%)*
• All percentages are related to the measuring value
Measurement on horizontal surfaces, mean value calculated from a minimum of 10 readings
