14.2 Delivery Schedule

14.2.1 Thickness gauge MiniTest 7200 FH / 7400 FH

Description

Order number

Thickness gauge MiniTest 7400 FH for non-magnetic materials

80-176-0000

Thickness gauge MiniTest 7200 FH for non-magnetic materials

80-177-0000

including:
Instruction manual in German/English/French on CD-Rom
Short instructions
4 x batteries AA (LR06),
Plastics carrying case, rubber protection case with positioning device and
shoulder belt, 1 magnetic screwdriver

14.2.2 Sensors

Description

Order number

Sensor FH4 for thickness measurement
measuring range: 0 ... 4.0 mm

including:
shielding tube
3 precision standards 0.25 mm, 1 mm, 3 mm
1 zero calibration standard for the target balls with 1.5 mm, 2.5 mm, 4 mm dia. (1
zero calibration standard per size)
1 spring loaded sensor stand
1 set of target balls with 1.5 mm and 2,5 mm dia.(100 balls each size)
1 set of target balls with 4 mm dia (50 balls)

80-174-0000

Sensor FH 10 for thickness measurement
measuring range: 1…10.0 mm

including
shielding tube
3 precision standards 1 mm, 3 mm, 8 mm
set of zero calibration standards for the target balls with 2.5mm, 4mm and 6mm
dia. (1 pc each ball size)
1 spring-loaded sensor stand
1 set of target balls with 2.5 mm dia. (100 balls)
1 set of target balls with 4 mm dia (50 balls)
1 set of target balls with 6 mm dia (25 balls)

80-175-0000
