Calibration modes:

Factory calibration, Zero point calibration and multi-point calibration ((Zero plus 1
to 4 calibration points)

Display:

LCD 160 x 160 pixel, backlit (user adjustable)

Measuring system:

metric (µm, mm) and imperial (mils)

Statistics functions:

Single readings, number of readings, min, max, average, standard deviation,
variation coefficient and process capability indices Cp and Cpk (only available
with MiniTest 7400 FH)

Data memory:

7200 FH

7400 FH

Maximum number of directories:

500 subdivided into 5 levels

Maximum number of batches:

1 200

Maximum number of readings:

100.000 240.000

Differential mode:

Display of the difference between current reading and preset set point

Statistics:

7200 FH:
numerical

7400 FH:
numerical, histogram, trend diagram

Languages:

English, German, French, Italian, Spanish, Portuguese

Interfaces:

IrDA, 1.0, Multi-purpose socket for RS232 TTL, footswitch, power supply unit and
alarm device

Operating temperature:

-10°C to + 60°C

Storing temperature:

-20°C to + 80°C

Protection class of gauge
housing:

IP 50

Dimensions and weight of gauge: 153 mm x 89 mm x 32 mm / 310 g including batteries

Dimensions and weight of FH 4
sensor

Ø 17 mm x 96 mm / 90 g

Dimensions and weight of FH 10
sensor:

Ø 30 mm x 125 mm / 300 g

Dimensions of plastics carrying
case:

365 mm x 450 mm x 140 mm

Power supply:

4 x 1,5 V LR 6 – AA baby cells, Power supply unit (90 to 240V AC /
48 - 62 Hz)
