Checkline FH Series User Manual

Page 30

7. Data Storage

7.1 Batches

7.1.1 General

Readings and their statistics will be stored in batches. Batches can be named alphanumerically

and stored in the database directly or under a certain directory. One batch is firmly installed under

the name “Direct Mode”. This batch cannot be deleted nor can it be renamed.

The model MiniTest 7200 FH does not include the database feature, but it offers one predefined

measuring batch.

7.1.2 Batch Data

7.1.2.1 Readings

One batch may include as many as 100,000 single readings plus statistics. The model MiniTest

7400 FH offers a maximum of 240,000 values in total.

7.1.2.2 Calibration Values

Calibration always refers to a certain measuring batch. As soon as a measuring batch is called, the

corresponding calibration will become active. The calibration includes the following parameter

settings: diameter of target ball, type of calibration and sensor.

7.1.2.3 Other Parameters

The parameters as set in the Configuration submenu such as Data logging mode, Logging rate,

Graphics (ON/OFF), Upper spec. limit, Lower spec. limit, and Setpoint refer to a certain batch and

will become valid as soon as this batch is called.
