APPENDIX B - Viscosity Ranges
The table below (Universal Spindle Ranges) lists the Spindle Range Coefficients for all spindles used
on DV-III Ultra Rheometers. Dividing the coefficient number by any of the 2,500 Rheometer speeds
will give the full scale viscosity range for a Rheometer/spindle/speed combination.
Universal Spindle Ranges
Spindle Entry Code
SPINDLE RANGE COEFFICIENT
Rheometer Series
LV RV HA HB
RV1 01 937 10,000 20,000 80,000
RV2 02 3,750 40,000 80,000 320,000
RV3 03 9,375 100,000 200,000 800,000
RV4 04 18,750 200,000 400,000 1,600,000
RV5 05 37,500 400,000 800,000 3,200,000
RV6 06 93,750 1,000,000 2,000,000 8,000,000
RV7 07 375,000 4,000,000 8,000,000 32,000,000
HA1 01 937 10,000 20,000 80,000
HA2 02 3,750 40,000 80,000 320,000
HA3 03 9,375 100,000 200,000 800,000
HA4 04 18,750 200,000 400,000 1,600,000
HA5 05 37,500 400,000 800,000 3,200,000
HA6 06 93,750 1,000,000 2,000,000 8,000,000
HA7 07 375,000 4,000,000 8,000,000 32,000,000
HB1 01 937 10,000 20,000 80,000
HB2 02 3,750 40,000 80,000 320,000
HB3 03 9,375 100,000 200,000 800,000
HB4 04 18,750 200,000 400,000 1,600,000
HB5 05 37,500 400,000 800,000 3,200,000
HB6 06 93,750 1,000,000 2,000,000 8,000,000
HB7 07 375,000 4,000,000 8,000,000 32,000,000
LV1 61 6,000 64,000 128,000 512,000
LV2 62 30,000 320,000 640,000 2,560,000
LV3 63 120,000 1,280,000 2,560,000 10,240,000
LV4 64 600,000 6,400,000 12,800,000 51,200,000
LV5 65 1,200,000 12,800,000 25,600,000 102,400,000
T-A 91 18,750 200,000 400,000 1,600,000
T-B 92 37,440 400,000 800,000 3,200,000
T-C 93 93,600 1,000,000 2,000,000 8,000,000
T-D 94 187,200 2,000,000 4,000,000 16,000,000
T-E 95 468,000 5,000,000 10,000,000 40,000,000
T-F 96 936,000 10,000,000 20,000,000 80,000,000
