FOR SPEED SETS WITH ZERO STEP TIMES

Program Use: _________________________________________________________
Programmer: _________________________________________________________

BROOKFIELD DV-III+ RHEOMETER — DATA FOR SPEED SET #8

SPEED #01 RPM = 10.0 TIME INTERVAL = 00:00

SPEED #02 RPM = 20.0 TIME INTERVAL = 00:00

SPEED #03 RPM = 30.0 TIME INTERVAL = 00:00

SPEED #04 RPM = 40.0 TIME INTERVAL = 00:00

Since speed sets can contain twenty-five (25) separate speeds, printing the speeds that comprise a

speed set will be of great help in allowing the user to fully exercise the power of the DV-III Ultra.

After the printing is complete, the user will be returned to the display of Figure IV-9.

CLEARING A SPEED SET FROM MEMORY

Since 10 speed sets can be retained in memory, the user may eventually use all the available speed

set slots. The user may also have programmed speed sets that are no longer required and would

like to remove. Assume that the user had programmed a new speed set #3 above. If he wished to

permanently remove that new speed set, or any other IN MEMORY speed set he would, while in

the screens of Figure IV-2, press the “2” key and be presented with:

CLEAR SPEED SET

IN MEM:0123589

IN USE:3

CLEAR SET:_

Figure IV-11

This screen advises that there are 7 speed sets in memory; speed set #3 is in use and that the DV-III

Ultra is awaiting input for the speed set to delete.

Note:

If no speed set is in use the word “NONE” will appear next to the IN USE: prompt.

At this point, the user has two options:

1. Pressing the MOTOR ON/OFF/ESCAPE key will exit from this screen and no speed sets

will be cleared. Or

2. Pressing any of the keys “0”, “1”, “2”, “3”, “5”, “8”, or “9” will delete that speed set.

Thus, to discard speed set #5, the user would press the “5” key and be presented with:

DELETE SPEED SET 5

ARE YOU SURE?

1 = YES 3 = NO

Figure IV-12
