ITEM
FORMAT
RANGE
EXAMPLE
RPM
RPM
X.XX
XX.X
XXX.X
0.01 <= RPM
<= 0.99
0.1 <= RPM
<= 99.9
100 <= RPM
<= 250
0.09
2.4
150.0
Model
M
XXXXX
See Model Table D-2 - Appendix D
RV
Spindle
S
XX
00 <= S
<= 99
31
Torque
T
XX.X
-10.1 <= T
<= 99.9
82.4
Viscosity
cP or mPas
X.XX
XXX.X
XXXXX
XXXeX
0 <= cP
<= 9.99
10 <= cP
<= 999.9
1000 <= cP
<= 99999
100000 <= cP
<= 51200000000
3.16
123.8
12345
123e3 to 8
Shear Stress
D/CM2 or
N/M2 =
D/CM 2/10
X.XX
XXX.X
XXXXX
XXXeX
0 <= D/CM2
<= 9.99
10 <= D/CM2
<= 999.9
1000 <= D/CM2
<= 99999
100000 <= D/CM2
<= 999999
4.56
234.5
12345
123e3
Shear Rate
1/SEC
X.XXX
XX.X
XXXXX
0 <= 1/SEC
<= 9.999
10 <= 1/SEC
<=99.9
100 <= 1/SEC
<= 99999
1.234
20.7
200
Temperature
T
-99.9 <= T
<= 300.0
-10.3
Time
Z
XX:XX
00:00 <= Z
<= 99.59
05:32
Table II-1
S
OUT OF RANGE INDICATORS
The DV-III Ultra is capable of measuring instrument torque within the range of 0 to 100%. Based
on this measurement, viscosity and shear stress are calculated. Brookfield recommends that data be
collected only in the range of 10 to 100%. Any data collected outside of this range is considered
invalid.
The DV-III Ultra provides the following display indicators when the measurement point is outside
of the 10-100% acceptable range.
S
TORqUE GREATER THAN 100%
When Rheometer torque exceeds 100%, the parameter display field will show “EEEE” for torque,
viscosity and shear stress.
RPM: 112 SPINDLE: 31
TEMP: 72.1°F PRTN
TORQUE = EEEE %
Figure II-4
S
TORqUE LESS THAN 10%
When Rheometer torque drops below ten (10) percent, the Rheometer will continue to display
measurement (%, cP, D/cm
2
) values with units flashing:
