The following screen is displayed:
#5: Sample Tst S:71
YIELD ERROR
OVER-RANGE
PRESS ESC OR ENTER
Figure IV-86
User-Defined Limit Condition
When an upper and lower limit has been imposed upon the Yield Stress by the user, any resulting
Yield Stress that falls outside these limits causes the test to fail with a Limit Violation Condition.
One of the following messages is sent to the attached printer dependent upon which limit was
violated:
Low Limit Violation
Test (#5: Sample Tst) Complete
Yield Stress (Pa) = 196.53 % Torque @ Yield = 27.4 Temperature = 250.5C
Test Failed = Yield Stress Below Low Limit
High Limit Violation
Test (#5: Sample Tst) Complete
Yield Stress (Pa) = 996.53 % Torque @ Yield = 78.6 Temperature = 250.5C
Test Failed = Yield Stress Above High Limit
The following screen, showing first the actual yield stress followed by the violated limit value, is
displayed:
#5: Sample Tst S:71
LIMIT ERROR
YIELD = 996.53 (800)
PRESS ESC OR ENTER
Figure IV-87
Test Cancelled By User
When a test is cancelled by the user, either by pressing the ESC key during a running test or by
canceling the test via the EZ-Yield TM software (See Section IV.8.2), the following is sent to the
attached printer:
Test (#test number: test name) Cancelled
Test Failed = Cancelled By User
The following screen is displayed:
#5: Sample Tst S:71
USER TERMINATED TEST
PRESS ESC OR ENTER
Figure IV-88
