REVIEW DATA

1 = SCREEN ONLY
2 = SCREEN & PRINT
3 = PRINTER ONLY

Figure V-2

4) Select one of the review modes: press “

NUMBER 1

” for DV-III Ultra screen only, “

NUMBER

” for DV-III Ultra screen and printer, or “

NUMBER 3

” for printer only. Note that you should

select options 2 and 3 only if the printer is connected and “on-line.”

5) If

NUMBER 1

NUMBER 2

were pressed, data from the first step is either displayed on the

screen or displayed and printed. Press the

ENTER

key to scroll through and display/print the

remaining step data.

cP=10800

STEP01

%=50.2

TIME=00:00

SS=0.0

TEMP=70.2

SR=0.0

RPM=100.0

Figure V-3

6) If the

NUMBER 3

key (printer only) is selected, the DV-III Ultra prompts to

“READY PRINTER

PRESS ANY KEY” or “PRINTER IS NOT READY TURN ON/PRESS ONLINE”

. A sample of printed

output is shown in Figure V-4.

Sample Name:_____________________________________________________________

Operater Name:____________________________

Date: 06/21/91 Time: 10:06 Model: 2R Spindle: 31

#01 RPM=30.0 %=18.2 cP=970 D/CM2=100 1/SEC=10.2 T=22.1C TIME=00:05

#02 RPM=40.0 %=24.3 cP=972 D/CM2=132 1/SEC=13.6 T=22.1C TIME=00:05

#03 RPM=50.0 %=30.3 cP=969 D/CM2=164 1/SEC=17.0 T=22.1C TIME=00:05

#04 RPM=60.0 %=36.3 cP=967 D/CM2=197 1/SEC=20.4 T=22.1C TIME=00:05

#05 RPM=70.0 %=42.3 cP=966 D/CM2=230 1/SEC=23.8 T=22.1C TIME=00:05

Figure V-4

Review data notes:

1) The DV-III Ultra stores data from the most recent speed set program test. When a

subsequent speed set program is run, any test data in memory will be overwritten and

the previous data will be lost.

2) If the “Printer Only” option is selected, the date, time of day, model and spindle

number are printed with the test results. The DV-III Ultra does not store time and date

when it is turned off; therefore, the time and date must be entered when printing the

first time after start-up. See Section V.2.
