Spiral Adapter
Spiral
Spindle
Shear Rate
(sec- 1 )
Viscosity (cP)
LVDV-III Ultra RVDV-III Ultra HADV-III Ultra HBDV-III Ultra
SA-70
.677 - 67.7
(1 - 100 RPM) 98.4 -
98,416 1,050 - 1,050,000 2,100 - 2,100,000 8,400 - 8,400,000
Cone/Plate Rheometer
Cone Spindle
Shear Rate
(sec- 1 )
Viscosity (cP)
LVDV-III Ultra RVDV-III Ultra HADV-III Ultra HBDV-III Ultra
CP/CPE/CPA-40 0 - 1500 0.15 - 3,065 1.7* - 32,700 3.3 - 65,400 13.1 - 261,000
CP/CPE/CPA-41 0 - 400 0.58 - 11,510 6.2 - 122,800 12.3 - 245,600 49.1 - 982,400
CP/CPE/CPA-42 0 - 760 0.3 - 6,000 3.2 – 64,000 6.4 - 128,000 25.6 - 512,000
CP/CPE/CPA-51 0 - 768 2.4 - 47,990 25.6 - 512,000 51.2 - 1,024,000 205.0 - 4,096,000
CP/CPE/CPA-52 0 - 400 4.6 - 92,130 49.2 - 983,000 98.3 - 1,966,000 393.0 - 7,864,000
* Theoretical low limit is 1.7 cP. Practical low limit is 3 to 5 cP. LV torque instrument is recommended
for viscosity values <5 cP.
Helipath with T-Bar Spindles
T-Bar Spindle
Viscosity (cP)
LVDV-III Ultra RVDV-III Ultra HADV-III Ultra HBDV-III Ultra
T-A 156 - 187,460 2,000 - 200,000 4,000 - 4,000,000 16,000 - 16,000000
T-B 312 - 374,920 4,000 - 400,000 8,000 - 8,000,000 32,000 - 32,000,000
T-C 780 - 937,300 10,000 - 10,000,000 20,000 - 20,000,000 80,000 - 80,000,000
T-D 1,560 - 1,874,600 20,000 - 20,000,000 40,000 - 40,000,000 160,000 - 160,000,000
T-E 3,900 - 4,686,500 50,000 - 50,000,000 100,000 - 100,000,000 400,000 - 400,000,000
T-F 7,800 - 9,373,000 100,000 - 100,000,000 200,000 - 200,000,000 800,000 - 800,000,000
