Brookfield Engineering Laboratories, Inc. Page 51 Manual No. M98-211-E0912
ERROR
YOU CANNOT EXECUTE A
MATH MODEL BECAUSE NO
DATA IS IN BUFFER
Figure IV-39
If there is already data in the data buffer, the user will be presented with the following screen:
MATH MODELS
1 CASSON 4 PWR LAW
2 NCA/CMA 5 PASTE
3 BINGHAM
Figure IV-40
The user is informed that there are five (5) math models which can be used on the buffer data.
A model is selected by pressing the appropriate numeric key. No matter the model selected, the
following screen will be displayed for the duration of the mathematical analysis.
MATH MODEL
CALCULATING
Figure IV-41
When the calculations are complete, the results for the particular model will be displayed as
follows:
CASSON (STANDARD) cP
PLASTIC VISC: 3069
YIELD STRESS: 140.1
CONF OF FIT: 97.5
Figure IV-42
This screen, for the Standard CASSON Model, is typical for all five (5) of the math models. Note
the cP in the upper right-hand corner to remind the user that the values are cP based. It could have
been SI (if the user had opted for SI display in the SETUP menu) as shown on the next two (2) of
the following four (4) math model screens:
The user may elect to print test results in order to obtain hard copy results. This is accomplished by
pressing the PRINT key while any of the above screens are being displayed causing the following
to be printed:
S STANDARD CASSON PRINTOUT
Sample Name: ____________________________________________________
Operator Name: ___________________________________________________
Date: 01/14/1999 Time: 02:27 Math Model Results: CASSON (STANDARD)
