Installation Guide
Chapter 4 Install the system
31
Perform a final system operation check
Perform all of the steps in these sections, to make sure that the wireless Acuity LT
System is operating properly.
•
Final system components check
•
Received signal strength indication (RSSI) check
This system check may require two to three hours to complete, depending on your facility.
After the final system operation check, APs can be installed, as described in
If any part of the system is not working, refer to
Final system components check
For this check, use one of the following patient monitors:
•
Micropaq monitor
•
Propaq LTR monitor
•
Wireless Propaq CS monitor
To perform a final system components check
Table 5. Final system check for wireless Acuity LT System
Step
Activity
Pass/fail
(circle
one)
Comments
1.
Make sure that all power is off to Acuity LT System components,
including all patient monitors.
Apply power as follows:
a. Printer: Make sure that the printer is online and has paper.
b. UPS 1 (In equipment room)
c.
Additional UPS (if 4-7 APs)
d. UPS 2 (at nurses station)
CPU should start up when UPS 2 power is applied. If it does
not, press CPU front panel power button.
e. Acuity LT Central Station display(s)
Confirm that activity begins on the display screen(s).
Pass
Fail
2.
Confirm that the following device LEDs are active.
•
Both UPSs
•
CPU
•
switch
•
PoEs
•
APs
Pass
Fail
3.
Inspect the APs and confirm that within 2-3 minutes of receiving
power the green Link LED (3rd LED from left on front of the AP) is
continuously on.
Pass
Fail
